KELLY RYAN BAGGERS

Kelly Ryan Offers
The only 7’ bagger on the market
Benefits
No wheels to move
The machine is always in operating position
The tractor is positioned in the front-center of the machine
Standard Features:
Self-cleaning tunnel
48” rotor with packing bars with 1” tine caps
Cable drums to accommodate 150-ft. bag with some double wrap
1.5” diameter cable drum shaft
Mechanically adjustable no-rust chrome brake disc
662 conveyor chain
Hydraulic motor driven cross-conveyor
American-made RC-160 roller chain drive running in an oil bath
2-15/16” bore tapered TIMKEN main drive bearing
Double endplate prevents silage juice from reaching the main rotor bearing
New 15” tires
Optional Equipment:
Bondioli 2155 Gearbox
- Same gearbox as on our 8’, 9’, and 10’ baggers
- Gear ratio 2.42:1
Patented “Centerline” Raised Rotor
- Puts up to 15% more in the bag than bottom pack units
- Packs more punch from the center, with less H.P., for tighter, more uniform bags of feed
- Higher quality feed due to more even packing
Standard mechanical brake
- No matter how much the temperature changes, the mechanical brake keeps the tension consistent throughout the bagging process.
8', 9' & 10' Kelly Ryan
"Centerline" Bagger

Benefits:

Wheels and tongue rotate to travel position
Tongue centered for close bag spacing and road travel
Standard Features:
Self-cleaning tunnel
Cables single wrap up to 250’
Hydraulic or mechanical break
540 rpm PTO (1000 available)
Oil bath gearbox and drive chain
#160 roller chain main rotor drive
Mechanical or hydraulic driven conveyor
1’ one-piece tunnel extension
72” rotor with 65 packing bars
Wide bag cradle for large fold bags
#662 detachable conveyor chain
Dual mechanical brake calipers
12' Kelly Ryan Big Bagger

Benefits:

Affordable
Easy to operate
Bag big quantities in small areas
Tongue centered for close bag spacing and road travel
Standard Features:
100” rotor with 92 packing bars
- Puts up to 15% more in the bag than bottom-pack units
- Packs more punch from the center, with less H.P., for tighter, more uniform bags of feed
- Higher quality feed due to more even packing
Self-cleaning tunnel
Cables single wrap up to 250’
Hydraulic or mechanical break
1000 rpm PTO (540 available)
Oil bath gearbox and drive chain
#160 Super Precision roller chain main rotor drive (38% stronger than regular #160 chain)
Hydraulic driven conveyor
1’ one-piece tunnel extension
Wide bag cradle for large fold bags
Hydraulic cable rewind
Single mechanical brake calipers
Optional Features:
Hydraulic brake with hand pump and gauge

Centerline Pro Baggers
  Benefits:
Self-cleaning tunnel means no need for tunnel clean out.
Bagger and platform are individually wheeled for portability
Standard Features:
100” rotor with 92 packing bars with tine caps
- Puts up to 15% more in the bag than bottom-pack units
- Packs more punch from the center, with less H.P., for tighter, more uniform bags of feed
- Higher quality feed due to more even packing
Self-cleaning tunnel
14” cable drums with single-wrap cables for up to 200’ bag
2” diameter cable drum shaft
American-made RC-160 roller chain main roller drive
3 7/16” bore tapered TIMKEN roller bearing on drive and idler end
Dual mechanical brake calipers
Bag lift with cradle
Dual 667X pintle apron chains
- Provides positive load movement
Hydraulic cable rewind
2” double endplate
- Prevents silage juice from reaching the main motor bearing
Remote grease bank for all rotor bearings
Four-port hydraulic quick connect
- Makes setup easy
On-board hydraulic jacks
- Makes it easy to convert to operating position
Self-contained hydraulic system with 55-gallon reservoir
100” patented Centerline raised packing rotor
Bondioli 2201 Gearbox
- 540 or 1000 rpm PTO
- Same gearbox as 12’ Centerline, rated at 150 horsepower
Optional Features:

Hydraulic brake with hand pump and gauge

Bagger Tender
  Benefits
The moving hopper takes larger, heavier loads than a mounted platform on a bagger
Perfect for filling upright silos
Great for any material that needs to be uniformly fed into any system
Apron speed infinitely variable from either tractor seat
Self-contained hydraulics available on either size
Towing tongue removable for normal use
Standard Features, 14-Ton Unit:
Inside dimensions: 10’ X 16’ long
X 3 1/2' deep
Double 667H floor chains (4)
10-ton running-gear steering axle
Discharge full loads in as little as 6 minutes.
3 hydraulic-drive motors, no gearboxes
Safety shields on all drives
Double-formed box channel center floor support
7,000-lb. jack with wheel on each side to relieve the load on the skid
Standard Features, 17-Ton Unit:
Inside dimensions: 10’ X 20’ long
X 3 1/2' deep
Double 667X floor chains (4)
12-ton running-gear steering axle
Discharge full loads in as little as 7 1/2 minutes!
3 hydraulic-drive motors, no gearboxes
Safety shields on all drives
Double-formed box channel center floor support
7,000-lb. jack with wheel on each side to relieve the load on the skid
